TYPE | DOUBLE HEADED OBLIQUE TYPE |
INLET | "FLANGED -FLAT FACED (PCD: 180 mm, Holes: 8 no’s x 19mm Dia, flange: 220mm OD x 12 mm thk)" |
OUTLET | OUTLET OF 63 MM FEMALE INSTANTENEOUS COUPLING WITH LUGS |
DESIGN STD | IS:5290 - 1993 TYPE - B |
OPERATION | BY HAND WHEEL |
STEM | RISING |
HYDRAULIC TEST PRESSURE | 21 KGF/SQ.CM FOR 150 secs |
WATER TIGHTNESS | 14 KGF/SQ.CM FOR 150 secs |
FLOW TEST | 1800 LPM AT 7 Kg/cm2 |
PAINTING | PO RED shade as per IS 538, of IS:5 |
MOC | AVAILABLE IN GM / SS / AL MOC |
APPROVAL | ISI MARKED |
"Minimax" Double Headed Oblique Type Hydrant Valve, Inlet 100mm & Outlet 63mm Instantaneous, IS:5290, ABS Blank Cap.
